Leak Proof Design Water Weight Bag Easy To Fill Design With Large
Inlet Valves For Quick Setup
Description
Designed for precision weight calibration, Hongruntong Marine’s
Water Weight Bag is an industry-leading solution for safe and
cost-effective load testing of lifting and rigging equipment.
Constructed with reinforced, high-grade PVC/TPU materials, it
offers superior tensile strength, leak resistance, and ease of
deployment.
The adjustable fill capacity allows for controlled and incremental
loading, ensuring maximum safety during testing procedures. With
internationally certified quality and decades of expertise in
marine safety solutions, Hongruntong Marine delivers reliable
performance for offshore, industrial, and construction
applications.
Specifications
| Application | Proof Load Testing, Offshore Load Testing, Structural Load Testing,
Ship Load Testing, Industrial Equipment Testing, Research and
Development. |
| Content | 100% POLYVINYL CHLORIDE |
| Phthalate | 7P Phthalate Free (includes all Phthalates listed in CAL Prop 65,
CPSIA and REACH) |
| Backing Material Size | 1.8/2.0 Mm X 1.55m, Thickness Produced As Per Your Request. |
| Weight | 37.1 oz square yard/ 1450 +- 50 GSM |
| Special | UV Resistant |
| 7P Phthalate Free (includes all Phthalates listed in CAL Prop 65,
CPSIA and REACH) |
| BPA Free / Tris Free / Formaldehyde Free |
| Does Not Contain Conflict Minerals |
| Care Instructions | Rinse With Fresh Water And Air Dry |
| Do Not Store with Seawater and Keep Away From Heat Sources |
| Available sizes | 5000 kg |
| 8,000 kg |
| 1,0000 kg |
| 15,000 kg |
| 20,000 kg |
| 30,000 kg |
| 50,000 kg |
| 100,000 kg |
| Special sizes could be customized |
| OEM | Supported |
| MODEL | Weight | Volume | Empty Height (Length) | Filled Height (Length) | Max Diam (ø) | Dry Weight without accessories |
| kg | Liters / m3 | m | m | m | kg |
| lbs | USG | ft | ft | ft | lbs |
| HM-1T | 1,000 | 1,000 / 1 | 2.52 | 2.23 | 1.39 | 36 |
| 2,204 | 264 | 8.27 | 7.33 | 4.56 | 80 |
| HM-2T | 2,000 | 2,000 / 2 | 2.87 | 2.6 | 1.65 | 41 |
| 4,409 | 528 | 9.41 | 8.5 | 5.43 | 90 |
| HM-3T | 3,000 | 3,000 / 3 | 3.38 | 2.97 | 1.82 | 50 |
| 6,613 | 792 | 11.11 | 9.75 | 6.0 | 110 |
| HM-4T | 4,000 | 4,000 / 4 | 3.41 | 3.07 | 1.88 | 64 |
| 8,818 | 1,056 | 11.22 | 10.1 | 6.16 | 141 |
| HM-5T | 5,000 | 5,000 / 5 | 4.14 | 3.52 | 2.13 | 80 |
| 11,023 | 1,320 | 13.60 | 11.58 | 7.0 | 176 |
| HM-6T | 6,000 | 6,000 / 6 | 4.39 | 3.91 | 2.28 | 86 |
| 13,227 | 1,585 | 14.41 | 12.83 | 7.48 | 189 |
| HM-8T | 8,000 | 8,000 / 8 | 4.54 | 3.93 | 2.52 | 104 |
| 17,636 | 2,113 | 14.91 | 12.91 | 8.27 | 230 |
| HM-10T | 10,000 | 10,000 / 10 | 5.18 | 4.49 | 2.70 | 130 |
| 22,046 | 2,641 | 17.0 | 14.75 | 8.90 | 286 |
| HM-12.5T | 12,500 | 12,500/ 12.5 | 5.43 | 4.62 | 2.86 | 154 |
| 27,558 | 3,302 | 17.91 | 15.16 | 9.39 | 340 |
| HM-15T | 15,000 | 15,000 / 15 | 6.24 | 5.48 | 2.95 | 159 |
| 33,069 | 3,962 | 20.50 | 18.00 | 9.70 | 350 |
| HM-20T | 20,000 | 20,000 / 20 | 6.78 | 6. 04 | 3.42 | 224 |
| 44,100 | 5,283 | 22.25 | 19.83 | 11.25 | 492 |
| HM-25T | 25,000 | 25,000 / 25 | 7.51 | 6.40 | 3.75 | 315 |
| 55,115 | 6,604 | 24.66 | 21.0 | 12.33 | 695 |
| HM-35T | 35,000 | 35,000 / 35 | 8.07 | 7.11 | 3.91 | 417 |
| 77,161 | 9,246 | 26.50 | 23.33 | 12.83 | 920 |
| HM-40T | 40,000 | 40,000 / 40 | 8.71 | 7.72 | 4.07 | 440 |
| 88,184 | 10,566 | 28.58 | 25.33 | 13.36 | 970 |
| HM-50T | 50,000 | 50,000 / 50 | 8.99 | 7.77 | 4.56 | 544 |
| 110,231 | 13,208 | 29.50 | 25.50 | 14.96 | 1200 |
| HM-100T | 100,000 | 100,000 / 100 | 11.27 | 10.00 | 5.65 | 952 |
| 220,462 | 26,420 | 37.00 | 32.9 | 18.56 | 2100
|
Features
Multi Layer Reinforced Fabric
Enhances durability and provides a longer operational lifespan.
Stable and Balanced Lifting
Designed to prevent sudden movements or instability during
underwater operations.
Quick Deployment & Recovery
Reduces downtime and labor costs by enabling fast setup and
retrieval.
Trusted by Marine Professionals
Used by global salvage teams, offshore engineers, and underwater
construction firms.
Backed by 30+ Years of Expertise
Manufactured by Hongruntong Marine, a leading provider of
professional marine lifting solutions.
Applications
● Marine vessel stability testing
● Offshore platform load assessment
● Crane certification and testing
● Bridge load capacity testing
● Construction equipment calibration
Advantages
Technical Expertise
In-house expertise to assist customers with technical advice and
solutions.
Comprehensive Catalog
A wide range of products to cover various testing requirements.
Multi Layer Construction
Enhanced durability through multi-layer designs that resist wear
and tear.
Lightweight Design
Efficient design that makes handling and transportation easier for
users.
FAQ
1. What is the weight capacity of a Water Weight Bag?
Capacities vary, but they can range from a few hundred kilograms to
several tons.
2. How accurate are Water Weight Bags for load testing?
They provide highly accurate load measurements when filled to the
specified volume.
3. Can Water Weight Bags be customized?
Yes, they can be tailored in size, shape, and weight capacity to
meet specific requirements.
4. What is the lifespan of a Water Weight Bag?
With proper care, they can last for many years, depending on usage
and environmental conditions.
5. Are Water Weight Bags resistant to harsh environments?
Yes, they are designed to withstand UV exposure, saltwater, and
extreme temperatures.
