Heavy Lift Test Bags Safe For Structures No Permanent Load Flexible
Placement
Description
Water bags are widely used in civil engineering, construction, and
research for accurate load simulation. They are ideal for bridge
load testing, floor capacity assessments, roof deflection tests,
and beam stress analysis. Their portability and quick setup make
them suitable for remote or confined job sites where traditional
weights are impractical. Additionally, they support dynamic and
static testing, enabling engineers to validate structural safety
under real-world conditions. With no permanent installation
required, water bags minimize project downtime while ensuring
reliable, repeatable test results.
Specifications
| Application | Proof Load Testing, Offshore Load Testing, Structural Load Testing,
Ship Load Testing, Industrial Equipment Testing, Research and
Development. |
| Content | 100% POLYVINYL CHLORIDE |
| Phthalate | 7P Phthalate Free (includes all Phthalates listed in CAL Prop 65,
CPSIA and REACH) |
| Backing Material Size | 1.8/2.0 MM X 1.55M, thickness produced as per your request. |
| Weight | 37.1 oz square yard/ 1450 +- 50 GSM |
| Special | UV Resistant |
| 7P Phthalate Free (includes all Phthalates listed in CAL Prop 65,
CPSIA and REACH) |
| BPA Free / Tris Free / Formaldehyde Free |
| Does not contain Conflict Minerals |
| Care Instructions | Rinse with fresh water and air dry |
| Do not store with seawater and keep away from heat sources |
| Available sizes | 5000 kg |
| 8,000 kg |
| 1,0000 kg |
| 15,000 kg |
| 20,000 kg |
| 30,000 kg |
| 50,000 kg |
| 100,000 kg |
| Special sizes could be customized |
| OEM | Supported |
| MODEL | Weight | Volume | Empty Height (Length) | Filled Height (Length) | Max Diam (ø) | Dry Weight without accessories |
| kg | Liters / m3 | m | m | m | kg |
| lbs | USG | ft | ft | ft | lbs |
| HM-1T | 1,000 | 1,000 / 1 | 2.52 | 2.23 | 1.39 | 36 |
| 2,204 | 264 | 8.27 | 7.33 | 4.56 | 80 |
| HM-2T | 2,000 | 2,000 / 2 | 2.87 | 2.6 | 1.65 | 41 |
| 4,409 | 528 | 9.41 | 8.5 | 5.43 | 90 |
| HM-3T | 3,000 | 3,000 / 3 | 3.38 | 2.97 | 1.82 | 50 |
| 6,613 | 792 | 11.11 | 9.75 | 6.0 | 110 |
| HM-4T | 4,000 | 4,000 / 4 | 3.41 | 3.07 | 1.88 | 64 |
| 8,818 | 1,056 | 11.22 | 10.1 | 6.16 | 141 |
| HM-5T | 5,000 | 5,000 / 5 | 4.14 | 3.52 | 2.13 | 80 |
| 11,023 | 1,320 | 13.60 | 11.58 | 7.0 | 176 |
| HM-6T | 6,000 | 6,000 / 6 | 4.39 | 3.91 | 2.28 | 86 |
| 13,227 | 1,585 | 14.41 | 12.83 | 7.48 | 189 |
| HM-8T | 8,000 | 8,000 / 8 | 4.54 | 3.93 | 2.52 | 104 |
| 17,636 | 2,113 | 14.91 | 12.91 | 8.27 | 230 |
| HM-10T | 10,000 | 10,000 / 10 | 5.18 | 4.49 | 2.70 | 130 |
| 22,046 | 2,641 | 17.0 | 14.75 | 8.90 | 286 |
| HM-12.5T | 12,500 | 12,500/ 12.5 | 5.43 | 4.62 | 2.86 | 154 |
| 27,558 | 3,302 | 17.91 | 15.16 | 9.39 | 340 |
| HM-15T | 15,000 | 15,000 / 15 | 6.24 | 5.48 | 2.95 | 159 |
| 33,069 | 3,962 | 20.50 | 18.00 | 9.70 | 350 |
| HM-20T | 20,000 | 20,000 / 20 | 6.78 | 6. 04 | 3.42 | 224 |
| 44,100 | 5,283 | 22.25 | 19.83 | 11.25 | 492 |
| HM-25T | 25,000 | 25,000 / 25 | 7.51 | 6.40 | 3.75 | 315 |
| 55,115 | 6,604 | 24.66 | 21.0 | 12.33 | 695 |
| HM-35T | 35,000 | 35,000 / 35 | 8.07 | 7.11 | 3.91 | 417 |
| 77,161 | 9,246 | 26.50 | 23.33 | 12.83 | 920 |
| HM-40T | 40,000 | 40,000 / 40 | 8.71 | 7.72 | 4.07 | 440 |
| 88,184 | 10,566 | 28.58 | 25.33 | 13.36 | 970 |
| HM-50T | 50,000 | 50,000 / 50 | 8.99 | 7.77 | 4.56 | 544 |
| 110,231 | 13,208 | 29.50 | 25.50 | 14.96 | 1200 |
HM-100T | 100,000 | 100,000 / 100 | 11.27 | 10.00 | 5.65 | 952 |
| 220,462 | 26,420 | 37.00 | 32.9 | 18.56 | 2100 |
Features
Uniform Weight Distribution
Eliminates stress concentrations for reliable test results.
UV Weather Resistant
Withstands outdoor conditions without degradation.
Customizable Load Capacity
Modular design allows flexible weight configurations.
Non Damaging to Structures
Soft, flexible contact prevents surface damage.
Applications
• Seismic Vibration Simulation
• Scaffolding Temporary Structure Testing
• Crane Lifting Equipment Certification
• Balcony Cantilever Load Verification
Advantages
Precise Weight Calibration
Ensures accurate load simulation (±1-2% tolerance).
Quick Fill Drain Valve Systems
High-flow ports for fast setup.
Uniform Load Distribution
Prevents stress concentrations on structures.
Modular Stackable Design
Scalable for small to mega-load tests.
Non Slip Base Options
Enhances stability on smooth surfaces.
FAQ
1. What’s their typical lifespan?
Years of use with proper care, depending on environment and
frequency.
2. How accurate are they for load simulation?
Highly precise; weight is calculated by water volume (1 liter = 1
kg).
3. Can they be used for dynamic testing (e.g., seismic
simulations)?
Yes, some models are designed for dynamic loads.
4. Do they work on uneven surfaces?
Yes, they conform to contours without concentrated stress.
