0.5M Expert Technical Support Marine Ship Launching Rubber Air Bag
For Ship
Description
Marine air bags are versatile lifting tools that help in lifting
large, heavy objects from underwater, such as sunken vessels,
debris removal, and construction equipment. Designed with
heavy-duty PVC material, the bags provide superior durability and
resistance to UV degradation. They are commonly used in offshore
operations, harbor salvage, and pipeline installation projects. The
air bags feature overpressure relief valves and reinforced lift
straps for safety and efficiency. For inflation, simply connect an
air compressor or scuba tank, and ensure gradual inflation for
stability. Packaging is secure, and we guarantee fast,
international shipping. Payment options include bank wire transfer,
and we accept L/C for larger orders. We also provide warranty
support for product repairs and replacements if issues arise
post-purchase.
Specifications
| Product Name | Marine Air Bag |
| Material | 100% High Tensile NR |
| Dimensions | Diameter 0.5m - 3.0m, Length 3.0m - 28.0m, or as Request |
| Working Pressure | 0.05-0.25MPA |
| Technology | Overall Winding, High Pressure, Explosion-proof |
| Metal Parts | Q355 / SS304 / SS316 |
| OEM | Supported |
| MOQ | 1 |
| Repair Tools | Electric Heating Plate, Repair Materials, Glue, Free of Charge |
| Standard | ISO14409:2011 |
| Certificate | ABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS |
| Package | Pallets, Wooden Cases |
| Service Life | 20 Years |
| Warranty | 36 Months |
| Diameter | Working Pressure | Working Height | Bearing Capacity |
| KN/m | Ton/m |
| D=1.0m | 0.14Mpa | 0.6m | 87.96 | 8.98 |
| 0.5m | 109.96 | 11.22 |
| 0.4m | 131.95 | 13.46 |
| D=1.2m | 0.12Mpa | 0.7m | 94.25 | 9.62 |
| 0.6m | 113.10 | 11.54 |
| 0.5m | 131.95 | 13.46 |
| 0.4m | 150.80 | 15.39 |
| D=1.5m | 0.10Mpa | 0.9m | 94.25 | 9.62 |
| 0.8m | 109.96 | 11.22 |
| 0.7m | 125.66 | 12.82 |
| 0.6m | 141.37 | 14.43 |
| 0.5m | 157.08 | 16.03 |
| D=1.8m | 0.09Mpa | 1.1m | 98.96 | 10.10 |
| 1.0m | 113.10 | 11.54 |
| 0.9m | 127.33 | 12.98 |
| 0.8m | 141.37 | 14.43 |
| 0.7m | 155.51 | 15.87 |
| 0.6m | 169.65 | 17.31 |
| D=2.0m | 0.08Mpa | 1.2m | 100.53 | 10.26 |
| 1.1m | 113.10 | 11.54 |
| 1.0m | 125.66 | 12.82 |
| 0.9m | 138.23 | 14.11 |
| 0.8m | 150.80 | 15.39 |
| 0.7m | 163.36 | 16.67 |
| 0.6m | 175.93 | 17.95 |
| * Other size can be provided follow client's requirements. |
Features
Safe and Controlled Lifting
The combination of overpressure relief valves, reinforced
construction, and multiple inflation points ensures safe and
controlled lifting, reducing the risk of failure during use.
Long Term Durability
With proper maintenance, marine air bags are designed to last for
years, offering exceptional durability and reliability for
long-term use in demanding environments.
Easy Storage and Transport
The foldable and lightweight design of marine air bags makes them
easy to store and transport, ensuring convenience for marine crews
who need to quickly mobilize for projects.
Non Toxic Materials
Marine air bags are made with non-toxic, environmentally friendly
materials, ensuring they don’t harm marine ecosystems during their
use.
Applications
● Lifting and relocating underwater rocks and boulders
● Offshore wind farm installation
● Platform rigging and lifting
● Underwater construction material transport
● Dock and pier repairs
Advantages
Customer Centric Approach
We prioritize customer satisfaction by maintaining open
communication, timely deliveries, and addressing any concerns
raised by clients.
Cost effectiveness
Our efficient manufacturing processes and economies of scale allow
us to offer competitive pricing without compromising on quality.
Environmental Responsibility
We adhere to environmentally friendly manufacturing practices,
ensuring our products align with sustainability goals.
After-Sales Support
Our commitment to clients extends beyond the sale; we provide
ongoing support and assistance, ensuring proper usage and
maintenance of our products.
FAQ
1. Are Marine Air Bags compatible with any lifting equipment?
Yes, Marine Air Bags are compatible with various lifting systems,
including cranes, winches, and marine vessels.
2. How do I inflate a large Marine Air Bag?
Large Marine Air Bags may require an industrial air compressor for
faster and more efficient inflation.
3. Can Marine Air Bags lift multiple objects at once?
Yes, Marine Air Bags can be used in tandem to lift multiple
objects, depending on the total weight and size.
4. Do you offer custom sizes for Marine Air Bags?
Yes, we offer custom sizes based on specific project requirements,
ensuring the best fit for your operation.
