Ship Launching Use Marine Rubber Air Bag Ccs Boat Lifting
Description
Marine Air Bags are specialized inflatable devices designed for
various applications in the marine industry, including ship
launching, marine salvage, and underwater lifting operations. These
robust and versatile bags are constructed from high-strength
materials, ensuring durability and resistance to harsh underwater
environments. Their large buoyancy capacity allows for the safe
lifting and relocation of vessels and heavy objects, making them an
essential tool for marine contractors and salvage operations. With
their lightweight design and ease of deployment, Marine Air Bags
can significantly reduce the time and labor involved in such tasks,
enhancing overall operational efficiency. They are available in
different sizes and configurations to meet specific project
requirements, making them a customizable solution for diverse
marine applications.
Specifications
| Product Name | Marine Air Bag |
| Material | 100% High Tensile NR |
| Dimensions | Diameter 0.5m - 3.0m, Length 3.0m - 28.0m, or as Request |
| Working Pressure | 0.05-0.25MPA |
| Technology | Overall Winding, High Pressure, Explosion-proof |
| Metal Parts | Q355 / SS304 / SS316 |
| OEM | Supported |
| MOQ | 1 |
| Repair Tools | Electric Heating Plate, Repair Materials, Glue, Free of Charge |
| Standard | ISO14409:2011 |
| Certificate | ABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS |
| Package | Pallets, Wooden Cases |
| Service Life | 20 Years |
| Warranty | 36 Months |
| Diameter | Working Pressure | Working Height | Bearing Capacity |
| KN/m | Ton/m |
| D=1.0m | 0.14Mpa | 0.6m | 87.96 | 8.98 |
| 0.5m | 109.96 | 11.22 |
| 0.4m | 131.95 | 13.46 |
| D=1.2m | 0.12Mpa | 0.7m | 94.25 | 9.62 |
| 0.6m | 113.10 | 11.54 |
| 0.5m | 131.95 | 13.46 |
| 0.4m | 150.80 | 15.39 |
| D=1.5m | 0.10Mpa | 0.9m | 94.25 | 9.62 |
| 0.8m | 109.96 | 11.22 |
| 0.7m | 125.66 | 12.82 |
| 0.6m | 141.37 | 14.43 |
| 0.5m | 157.08 | 16.03 |
| D=1.8m | 0.09Mpa | 1.1m | 98.96 | 10.10 |
| 1.0m | 113.10 | 11.54 |
| 0.9m | 127.33 | 12.98 |
| 0.8m | 141.37 | 14.43 |
| 0.7m | 155.51 | 15.87 |
| 0.6m | 169.65 | 17.31 |
| D=2.0m | 0.08Mpa | 1.2m | 100.53 | 10.26 |
| 1.1m | 113.10 | 11.54 |
| 1.0m | 125.66 | 12.82 |
| 0.9m | 138.23 | 14.11 |
| 0.8m | 150.80 | 15.39 |
| 0.7m | 163.36 | 16.67 |
| 0.6m | 175.93 | 17.95 |
| * Other size can be provided follow client's requirements. |
Features
Resistance to Abrasion
The materials used in manufacturing these air bags possess high
abrasion resistance, ensuring longevity even in rough underwater
conditions.
Safety Features
Equipped with safety valves and robust seals, marine air bags are
designed to prevent accidental deflation and ensure a safe lifting
experience.
Ease of Use
The simplicity in operating marine air bags makes them accessible
for personnel of varying skill levels, promoting efficient project
execution.
Environmental Compatibility
The materials used in the production are often environmentally
friendly, offering an eco-conscious option for heavy lifting
operations.
Applications
● Ship launching
● Vessel recovery
● Marine salvage operations
● Underwater lifting
Advantages
Expert Engineering Team
Our in house team of engineers and specialists ensures that each
product is designed and produced to meet the most demanding
operational requirements.
Enhanced Safety Features
Each Marine Air Bag is equipped with overpressure relief valves,
multiple inflation ports, and reinforced lifting points to provide
maximum safety during operation.
Durable and Long Lasting
Thanks to the use of high-quality materials, our Marine Air Bags
are designed to withstand abrasion, UV exposure, and saltwater
corrosion for long-term use.
Versatility in Application
Our Marine Air Bags are used in a wide range of applications,
including shipwreck recovery, underwater construction, salvage
operations, and offshore lifting.
FAQ
1. How do I maintain my Marine Air Bag?
To maintain your Marine Air Bag, store it in a dry, cool place, and
regularly inspect it for any signs of wear, leaks, or damage.
2. Can Marine Air Bags be repaired if damaged?
Yes, minor damages can be repaired with a specialized PVC repair
kit. For major damage, please contact our service team for
assistance.
3. Are Marine Air Bags reusable?
Yes, Marine Air Bags are designed for multiple uses, and with
proper maintenance, they can be reused for various operations.
4. Can I use Marine Air Bags in both freshwater and saltwater?
Yes, Marine Air Bags are designed to work effectively in both
saltwater and freshwater environments.
