ISO14409 Durable Marine Airbag Natural Rubber Inflatable Boat for
Ship Launching
Description
Our marine air bags are designed for lifting and recovering heavy
objects from underwater, such as sunken ships, construction
materials, and offshore structures. Made from heavy-duty PVC, these
air bags provide excellent tear and abrasion resistance, making
them ideal for harsh underwater conditions. They feature multiple
inflation valves for easy adjustment and overpressure relief valves
to ensure safe operation. The user manual provided includes
detailed instructions on inflation, attachment, and safety
precautions. For shipment, the air bags are securely packaged and
shipped globally. We accept bank transfers for payment, with L/C as
an option for larger orders. In the case of defective products,
please contact our support team within 30 days for returns or
replacements.
Specifications
| Product Name | Marine Air Bag |
| Material | 100% High Tensile NR |
| Dimensions | Diameter 0.5m - 3.0m, Length 3.0m - 28.0m, or as Request |
| Working Pressure | 0.05-0.25MPA |
| Technology | Overall Winding, High Pressure, Explosion-proof |
| Metal Parts | Q355 / SS304 / SS316 |
| OEM | Supported |
| MOQ | 1 |
| Repair Tools | Electric Heating Plate, Repair Materials, Glue, Free of Charge |
| Standard | ISO14409:2011 |
| Certificate | ABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS |
| Package | Pallets, Wooden Cases |
| Service Life | 20 Years |
| Warranty | 36 Months |
| Diameter | Working Pressure | Working Height | Bearing Capacity |
| KN/m | Ton/m |
| D=1.0m | 0.14Mpa | 0.6m | 87.96 | 8.98 |
| 0.5m | 109.96 | 11.22 |
| 0.4m | 131.95 | 13.46 |
| D=1.2m | 0.12Mpa | 0.7m | 94.25 | 9.62 |
| 0.6m | 113.10 | 11.54 |
| 0.5m | 131.95 | 13.46 |
| 0.4m | 150.80 | 15.39 |
| D=1.5m | 0.10Mpa | 0.9m | 94.25 | 9.62 |
| 0.8m | 109.96 | 11.22 |
| 0.7m | 125.66 | 12.82 |
| 0.6m | 141.37 | 14.43 |
| 0.5m | 157.08 | 16.03 |
| D=1.8m | 0.09Mpa | 1.1m | 98.96 | 10.10 |
| 1.0m | 113.10 | 11.54 |
| 0.9m | 127.33 | 12.98 |
| 0.8m | 141.37 | 14.43 |
| 0.7m | 155.51 | 15.87 |
| 0.6m | 169.65 | 17.31 |
| D=2.0m | 0.08Mpa | 1.2m | 100.53 | 10.26 |
| 1.1m | 113.10 | 11.54 |
| 1.0m | 125.66 | 12.82 |
| 0.9m | 138.23 | 14.11 |
| 0.8m | 150.80 | 15.39 |
| 0.7m | 163.36 | 16.67 |
| 0.6m | 175.93 | 17.95 |
| * Other size can be provided follow client's requirements. |
Features
High Buoyancy Capacity
Marine air bags are designed to provide significant buoyancy,
allowing them to lift heavy vessels and objects efficiently.
Durable Construction
Crafted from high-strength materials, these bags can withstand
harsh marine environments, including saltwater, UV exposure, and
extreme weather conditions.
Lightweight Design
Despite their strength, marine air bags are lightweight, making
them easy to transport and deploy in various marine applications.
Versatile Applications
These air bags can be used for multiple purposes such as ship
launching, marine salvage, underwater lifting, and more, making
them highly adaptable to different marine projects.
Applications
● Marine demolition
● Offshore equipment inspection and maintenance
● Deployment of underwater sensors and devices
● Heavy object repositioning in submerged areas
● Submarine cable repair operations
Advantages
Over 30 Years of Manufacturing Experience
With more than three decades in the industry, our expertise ensures
the highest standards of quality and innovation in every product.
Premium Material Quality
Our Marine Air Bags are made from high-strength, UV-resistant PVC,
ensuring exceptional durability and resistance to harsh marine
environments.
Customized Solutions
We offer tailored sizes and configurations to meet the specific
needs of each project, ensuring the best fit for any marine
operation.
Proven Track Record
We have successfully delivered thousands of Marine Air Bags for
various industries, including salvage, construction, and offshore
operations, establishing a strong reputation for reliability.
FAQ
1. How much weight can one Marine Air Bag lift?
The lifting capacity of each Marine Air Bag varies based on its
size and design, with some capable of lifting over 1,000 tons.
2. What type of valve is used for inflation?
Marine Air Bags use manual or automatic inflation valves, allowing
easy and controlled inflation and deflation.
3. Can I deflate the Marine Air Bag after use?
Yes, Marine Air Bags can be deflated through the same valve used
for inflation, and the air can be released gradually.
4. Are Marine Air Bags difficult to deploy?
No, Marine Air Bags are easy to deploy, and the inflation process
is straightforward, even for operators with minimal experience.
