Airbag Launching Ship Inflatable Rolling Rubber Airbag For Oil Tanker Launching

    Buy cheap Airbag Launching Ship Inflatable Rolling Rubber Airbag For Oil Tanker Launching from wholesalers

    Buy cheap Airbag Launching Ship Inflatable Rolling Rubber Airbag For Oil Tanker Launching from wholesalers
    • Buy cheap Airbag Launching Ship Inflatable Rolling Rubber Airbag For Oil Tanker Launching from wholesalers
    • Buy cheap Airbag Launching Ship Inflatable Rolling Rubber Airbag For Oil Tanker Launching from wholesalers
    • Buy cheap Airbag Launching Ship Inflatable Rolling Rubber Airbag For Oil Tanker Launching from wholesalers
    • Buy cheap Airbag Launching Ship Inflatable Rolling Rubber Airbag For Oil Tanker Launching from wholesalers

    Airbag Launching Ship Inflatable Rolling Rubber Airbag For Oil Tanker Launching

    Ask Lasest Price
    Brand Name : Hongruntong Marine
    Model Number : HM-ALS058
    Certification : ISO, BV, ABS, DNV, LR, SGS, CCS, RMRS
    Price : USD$10-USD$880
    Payment Terms : L/C, T/T, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 820 Pcs Per Month
    Delivery Time : 5-7 Work Days
    • Product Details
    • Company Profile

    Airbag Launching Ship Inflatable Rolling Rubber Airbag For Oil Tanker Launching

    Airbag Launching Ship Inflatable Rolling Rubber Airbag for Oil tanker launching


    Description


    Airbag launching is a highly efficient and eco friendly method for launching ships. It involves the use of inflatable marine airbags to roll a vessel into the water safely. This method eliminates the need for traditional infrastructure, significantly lowering operational costs. Ideal for both small and large vessels, airbag launching is widely adopted in shipyards due to its simplicity and versatility. Hongruntong Marine, with over 30 years of manufacturing expertise, offers top-of-the-line airbags that ensure safe, reliable launches. As a game changer in the industry, airbag launching combines advanced technology with cost-effective operations to meet the demands of modern shipbuilding.


    Airbag Launching Ship Inflatable Rolling Rubber Airbag For Oil Tanker LaunchingAirbag Launching Ship Inflatable Rolling Rubber Airbag For Oil Tanker Launching


    Specifications


    ItemDescription
    Place of OriginChina
    Brand NameHongruntong Marine
    Model NumberHM-ALS058
    MaterialIndustrial-Grade Natural Rubber
    Diameter0.5m-3.0m, or as Request
    Length1.0m-28.0m, or as Request
    Working Pressure0.05-0.25 mpa
    TechnicsHigh pressure, overall winding, explosion-proof
    Useship launching and docking
    Thickness5-13 ply
    StandardConducted by ISO14409 and GB/T1590-2006 system.
    AccessoriesQ355/SS304/SS316, Pressure Gauge, Tee, Plug, Switch, Inflation Tube
    PackagingInner-Plastic Bag; Outer-Standard Wooden Pallets.
    KeywordsAirbag Launching Ship
    CertificatesABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS
    MOQ1
    OEMWelcome

    Diameter

    Working

    Pressure

    Working

    Height

    Bearing Capacity
    KN/mTon/m
    D=1.0m0.14Mpa0.6m87.968.98
    0.5m109.9611.22
    0.4m131.9513.46
    D=1.2m0.12Mpa0.7m94.259.62
    0.6m113.1011.54
    0.5m131.9513.46
    0.4m150.8015.39
    D=1.5m0.10Mpa0.9m94.259.62
    0.8m109.9611.22
    0.7m125.6612.82
    0.6m141.3714.43
    0.5m157.0816.03
    D=1.8m0.09Mpa1.1m98.9610.10
    1.0m113.1011.54
    0.9m127.3312.98
    0.8m141.3714.43
    0.7m155.5115.87
    0.6m169.6517.31
    D=2.0m0.08Mpa1.2m100.5310.26
    1.1m113.1011.54
    1.0m125.6612.82
    0.9m138.2314.11
    0.8m150.8015.39
    0.7m163.3616.67
    0.6m175.9317.95
    * Other size can be produced follow client's requirements.

    Features


    Wide Operating Range

    Performs reliably in extreme temperatures and weather conditions.


    Minimal Training Required

    Simple operational procedures reduce the need for extensive training.


    Efficient for Repairs

    Allows launching and retrieval of ships undergoing maintenance or retrofitting.


    Innovative Design

    Incorporates advanced sealing and inflation technology for optimal performance.


    Applications


    Launching marine engineering equipment

    Heavy load object transportation
    Launching vessels on uneven terrains
    Relocating old vessels
    Emergency launching in remote areas

    Advantages


    Excellent Customer Support

    Dedicated after-sales service to ensure client satisfaction.


    On Site Training

    Assistance with installation and operational techniques for clients.


    Versatile Applications

    Airbags suitable for ship launching, salvage, and heavy object movement.


    High Friction Resistance

    Products designed to withstand abrasion and rough conditions.


    Airbag Launching Ship Inflatable Rolling Rubber Airbag For Oil Tanker LaunchingAirbag Launching Ship Inflatable Rolling Rubber Airbag For Oil Tanker Launching


    FAQ


    Q: Do airbags work in extreme weather?
    A: Yes, marine airbags are designed to perform reliably in various weather and temperature conditions.


    Q: Are your airbags certified?
    A: Yes, our airbags meet international quality and safety standards, such as ISO certifications.


    Q: Can airbags be used for ship repairs and retrofitting?
    A: Absolutely, airbags are excellent for docking ships for maintenance and upgrades.


    Q: How do airbags compare to traditional launching methods?
    A: Airbags are more flexible, cost-effective, and environmentally friendly than traditional slipways or cranes.
