Heavy Duty Inflatable Air Bags Heavy Duty Boat Lift Airbags for
Lifting
Description
When it comes to heavy lifting, many customers want to know: what
makes Heavy Duty Inflatable Air Bags the best choice for their
needs? One of the most compelling reasons is their high load
capacity, which can handle weights of up to 15 tons. This makes
them suitable for a wide range of applications, ensuring you can
lift heavy objects safely and reliably.
Another common question is about their operation. Users appreciate
how quick these air bags can be inflated and deflated. Using a
standard air compressor, you can go from storage to fully
operational within minutes, which is crucial during time-sensitive
operations.
Specifications
| Model | Lifting Capacity | Dimensions | Appr. Weight |
| Parachute | [kg] | [lbs] | [mm] | [kg] |
| HM-P01 | 200 | 441 | 800 | 5 |
| HM-P02 | 500 | 1,103 | 1,000 | 8 |
| HM-P03 | 1,000 | 2,205 | 1,300 | 11 |
| HM-P04 | 2,000 | 4,410 | 1,600 | 20 |
| HM-P05 | 4,000 | 8,820 | 2,000 | 50 |
| HM-P06 | 6,000 | 13,230 | 2,300 | 66 |
| HM-P07 | 8,000 | 17,640 | 2,500 | 75 |
| HM-P08 | 10,000 | 22,050 | 2,700 | 80 |
| HM-P09 | 15,000 | 33,075 | 3,100 | 110 |
| HM-P10 | 20,000 | 44,100 | 3,400 | 130 |
| HM-P11 | 30,000 | 66,150 | 3,900 | 170 |
| HM-P12 | 50,000 | 110,250 | 4,600 | 220 |
| HM-P13 | 70,000 | 154,350 | 5,200 | 310 |
| HM-P14 | 100,000 | 220,500 | 5,800 | 450 |
| HM-P15 | 150,000 | 330,750 | 6,600 | 660 |
| HM-P16 | 200,000 | 441,000 | 7,300 | 900 |
| *Note: Other sizes can be customized according to the requirements. |
| Model | Buoyancy | Diameter | Length | Appr. Weight |
| Cylindrical | [kg] | [lbs] | [mm] | [mm] | [kg] |
| HM-C01 | 200 | 441 | 500 | 1,000 | 5 |
| HM-C02 | 500 | 1,103 | 800 | 1,000 | 8 |
| HM-C03 | 1,000 | 2,205 | 1,000 | 1,500 | 11 |
| HM-C04 | 2,000 | 4,410 | 1,300 | 1,500 | 20 |
| HM-C05 | 4,000 | 8,820 | 1,600 | 2,000 | 50 |
| HM-C06 | 6,000 | 13,230 | 2,000 | 2,000 | 66 |
| HM-C07 | 8,000 | 17,640 | 2,000 | 2,600 | 75 |
| HM-C08 | 10,000 | 22,050 | 2,400 | 2,400 | 80 |
| HM-C09 | 15,000 | 33,075 | 2,600 | 3,000 | 110 |
| HM-C10 | 20,000 | 44,100 | 3,000 | 3,000 | 130 |
| HM-C11 | 30,000 | 66,150 | 3,000 | 4,500 | 170 |
| HM-C12 | 50,000 | 110,250 | 4,000 | 4,000 | 220 |
| HM-C13 | 70,000 | 154,350 | 4,000 | 5,700 | 310 |
| HM-C14 | 100,000 | 220,500 | 4,000 | 8,000 | 450 |
| HM-C15 | 150,000 | 330,750 | 5,000 | 8,000 | 660 |
| HM-C16 | 200,000 | 441,000 | 5,000 | 10,000 | 900 |
| *Note: Other sizes can be customized according to the requirements. |
Model | Capacity | Length | Width |
|---|
Pillow | [kg] | [lbs] | [mm] | [mm] |
|---|
| HM-P100 | 100 | 220 | 1,020 | 760 |
| HM-P250 | 250 | 550 | 1,320 | 820 |
| HM-P500 | 500 | 1,100 | 1,300 | 1,200 |
| HM-P1000 | 1,000 | 2,200 | 1,550 | 1,420 |
| HM-P2000 | 2,000 | 4,400 | 1,950 | 1,780 |
| HM-P3000 | 3,000 | 6,600 | 2,900 | 1,950 |
| HM-P5000 | 5,000 | 11,000 | 3,230 | 2,030 |
| *Note: Other sizes can be customized according to the requirements. |
Features
Quick Inflation and Deflation
Equipped with easily accessible valves for rapid deployment and
retraction, allowing for efficient operations.
Lightweight Design
Despite their tough construction, these bags are lightweight,
making them easy to transport and deploy by hand or with minimal
equipment.
Versatile Application
Ideal for a range of applications, including marine salvage,
underwater recovery, and oil spill containment.
Multi Size Options
Available in various sizes to meet the specific requirements of
different salvage operations.
Applications
● Cargo Recovery from Sunken Vessels
● Barge and Ship Stabilization
● Marine Debris Removal
● Diving Operations
● Flood Resilience and Recovery
Advantages
Exceptional Manufacturing Expertise
With over three decades of experience in the industry, our factory
has honed its manufacturing processes and techniques, ensuring the
highest standards of quality and precision in every Heavy Duty
Inflatable Air Bag produced. Our skilled workforce is dedicated to
delivering reliable and durable products.
High Quality Materials
We utilize premium-grade materials, such as reinforced PVC,
neoprene, and polyurethane, which provide excellent resistance to
abrasion, punctures, and harsh environmental conditions. This
commitment to high-quality materials guarantees the durability and
longevity of our inflatable air bags.
Customizable Solutions
Our extensive experience allows us to offer tailored solutions to
meet diverse client needs. We provide a variety of sizes, load
capacities, and additional features, enabling our customers to
select the perfect product for their specific applications and
requirements.
Strong Commitment to Safety
We prioritize safety in our manufacturing processes by
incorporating essential safety features, such as double-sealed
seams and pressure release valves. Our rigorous testing protocols
ensure that all products meet or exceed industry safety standards,
providing peace of mind to our customers during operation.
FAQ
1. How do I inflate the air bags?
Inflation can be achieved using a standard air pump, compressed
air, or through an air inflation system. The bags typically feature
an inflation valve for easy and quick inflation.
2. How do I determine which size air bag I need?
Choosing the right size air bag depends on the weight of the object
you wish to lift and the specific application. We recommend
consulting with our team or referring to our sizing guide for
assistance in selecting the appropriate model.
3. What safety features do your air bags have?
Our Heavy Duty Inflatable Air Bags come equipped with safety
features such as pressure relief valves, reinforced lifting points,
and double-sealed seams to prevent over-inflation and ensure secure
lifting operations.
4. Can the air bags be used multiple times?
Yes, our inflatable air bags are designed for repeated use. With
proper care and maintenance, they can last for many years, making
them a cost-effective choice for various applications.
