    Marine Rubber Airbag Lifting Airbag Salvage Rubber Airbags For Vessel Relocation

    Ask Lasest Price
    Brand Name : Hongruntong Marine
    Model Number : HMRA-18
    Certification : ISO, BV, ABS, DNV, LR, SGS, CCS, RMRS
    Price : US$280-US$800
    Payment Terms : L/C, T/T, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 690 Pcs Per Month
    Delivery Time : 5-7 Work Days
    • Product Details
    • Company Profile

    Marine Rubber Airbag Lifting Airbag Salvage Rubber Airbags For Vessel Relocation

    Marine Rubber Airbag Lifting Airbag Salvage Rubber Airbags for Vessel Relocation


    Description


    Tugging Marine Rubber Airbag Our Tugging Marine Rubber Airbags are specifically designed for towing and transporting large vessels or structures. With reinforced rubber and fabric layers, these airbags offer superior strength and durability to withstand the stress of continuous tugging operations in tough marine environments.


    Hongruntong Marine’s tugging airbags provide excellent buoyancy and balance, ensuring safe and efficient transport of vessels in both calm and rough waters. Their robust construction guarantees a long service life, even under extreme conditions.


    Marine Rubber Airbag Lifting Airbag Salvage Rubber Airbags For Vessel RelocationMarine Rubber Airbag Lifting Airbag Salvage Rubber Airbags For Vessel Relocation


    Specifications


    ItemDescription
    Place of OriginChina
    Brand NameHongruntong Marine
    MaterialNBR
    Diameter0.5m-3.0m, or as Request
    Length1.0m-28.0m, or as Request
    Working Pressure0.05-0.25 mpa
    TechnicsHigh pressure, overall winding, explosion-proof
    Useship launching and docking
    Thickness5-13 ply
    StandardConducted by ISO14409 and GB/T1590-2006 system.
    AccessoriesQ355/SS304/SS316, Pressure Gauge, Tee, Plug, Switch, Inflation Tube
    PackagingInner-Plastic Bag; Outer-Standard Wooden Pallets.
    KeywordsRubber Airbag
    CertificatesABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS
    MOQ1
    OEMWelcome

    Diameter

    Working

    Pressure

    Working

    Height

    Bearing Capacity
    KN/mTon/m
    D=1.0m0.14Mpa0.6m87.968.98
    0.5m109.9611.22
    0.4m131.9513.46
    D=1.2m0.12Mpa0.7m94.259.62
    0.6m113.1011.54
    0.5m131.9513.46
    0.4m150.8015.39
    D=1.5m0.10Mpa0.9m94.259.62
    0.8m109.9611.22
    0.7m125.6612.82
    0.6m141.3714.43
    0.5m157.0816.03
    D=1.8m0.09Mpa1.1m98.9610.10
    1.0m113.1011.54
    0.9m127.3312.98
    0.8m141.3714.43
    0.7m155.5115.87
    0.6m169.6517.31
    D=2.0m0.08Mpa1.2m100.5310.26
    1.1m113.1011.54
    1.0m125.6612.82
    0.9m138.2314.11
    0.8m150.8015.39
    0.7m163.3616.67
    0.6m175.9317.95
    * Other size can be produced follow client's requirements.

    Features


    Floating Crane Support

    Provides buoyancy support for floating crane operations.


    Mooring Assistance

    Helps stabilize vessels during docking or mooring operations.


    Temporary Dry Docking

    Provides temporary buoyancy for vessels under repair or maintenance.


    Bridge Construction

    Used in marine bridge construction for lifting and positioning heavy components.


    Offshore Platform Relocation

    Ideal for relocating large offshore platforms in offshore oil and gas operations.


    Applications


    Large vessel relocation

    Offshore construction support

    Floating platform positioning


    Advantages


    High Pressure Resistance

    Airbags designed to handle high pressure without compromising performance.


    Anti Corrosion Properties

    Resistant to corrosion from seawater, ensuring longevity and durability.


    User Friendly Design

    Easy to operate and maintain, even in challenging marine environments.


    Stable Performance

    Consistent performance under different conditions, including rough seas and extreme weather.


    Marine Rubber Airbag Lifting Airbag Salvage Rubber Airbags For Vessel RelocationMarine Rubber Airbag Lifting Airbag Salvage Rubber Airbags For Vessel Relocation
    FAQ
    1. Can Marine Rubber Airbags be repaired?
    Yes, minor damage like small punctures can often be repaired using special rubber repair kits, but larger damage may require replacing the airbag.
    2. How are Marine Rubber Airbags different from air cushions?
    Marine Rubber Airbags are designed specifically for marine environments and heavy lifting, whereas air cushions are typically used for lighter, more precise load movements in non marine contexts.
    3. What are the advantages of using Marine Rubber Airbags over traditional methods?
    Marine Rubber Airbags are flexible, portable, require less setup time, and can be used in various environmental conditions, making them a versatile solution.
    4. How do Marine Rubber Airbags contribute to environmental sustainability?
    They help reduce the need for heavy machinery, which lowers energy consumption and reduces the environmental impact of large lifting operations.
