Shipyard Ship Launching Airbags Flexible Structures Inflatable Marine Air Bag

    Buy cheap Shipyard Ship Launching Airbags Flexible Structures Inflatable Marine Air Bag from wholesalers

    Buy cheap Shipyard Ship Launching Airbags Flexible Structures Inflatable Marine Air Bag from wholesalers
    • Buy cheap Shipyard Ship Launching Airbags Flexible Structures Inflatable Marine Air Bag from wholesalers
    • Buy cheap Shipyard Ship Launching Airbags Flexible Structures Inflatable Marine Air Bag from wholesalers
    • Buy cheap Shipyard Ship Launching Airbags Flexible Structures Inflatable Marine Air Bag from wholesalers
    • Buy cheap Shipyard Ship Launching Airbags Flexible Structures Inflatable Marine Air Bag from wholesalers

    Shipyard Ship Launching Airbags Flexible Structures Inflatable Marine Air Bag

    Ask Lasest Price
    Brand Name : Hongruntong Marine
    Model Number : HM-SLA1.8M*20M
    Certification : ABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS
    Price : US$200-US$760
    Payment Terms : L/C, T/T, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 1060 Pcs Per Month
    Delivery Time : 5-7 Work Days
    • Product Details
    • Company Profile

    Shipyard Ship Launching Airbags Flexible Structures Inflatable Marine Air Bag

    Shipyard Ship Launching Salvage and Refloating Operations Marine Ship Vessel Launching Airbags


    Description


    Ship launching airbags are inflatable flexible structures designed to safely launch or upgrade ships and other vessels. Made of high-quality synthetic rubber, these airbags possess excellent wear resistance and load-bearing capacity.


    The ship launching process using airbags is efficient, cost-effective, and environmentally friendly. By distributing the load evenly, the airbags provide a cushioning effect, reducing the impact on the vessel during launch or dry-docking operations.


    Our ship launching airbags offer several advantages, including their ability to conform to the vessel's shape and accommodate different ship sizes. They can be easily installed and removed with minimal manpower and equipment.


    With our expertise in manufacturing ship launching airbags, we ensure strict quality control throughout the production process. Our products comply with international standards, guaranteeing their reliability and durability.


    Choose our ship launching airbags for a safe, efficient, and hassle-free solution to your ship launching and upgrading needs.


    Shipyard Ship Launching Airbags Flexible Structures Inflatable Marine Air Bag


    Specifications


    ItemDescription
    Place of OriginChina
    Brand NameHongruntong Marine
    Model NumberFT006
    MaterialReliable Natural Rubber
    Diameter0.5m-3.0m, or As Request
    Length1.0m-28.0m, or As Request
    Working Pressure0.05-0.25 mpa
    TechnicsHigh pressure, overall winding, explosion-proof
    Useship launching and docking
    Thickness5-15 ply
    StandardConducted by ISO14409 and GB/T1590-2006 system.
    AccessoriesQ355/SS304/SS316, Pressure Gauge, Tee, Plug, Switch, Inflation Tube
    PackagingInner-Plastic Bag; Outer-Standard Wooden Pallets.
    KeywordsMarine rubber airbags for ship launching
    CertificatesABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS
    MOQ1
    OEMWelcome

    Shipyard Ship Launching Airbags Flexible Structures Inflatable Marine Air Bag


    Shipyard Ship Launching Airbags Flexible Structures Inflatable Marine Air Bag


    Shipyard Ship Launching Airbags Flexible Structures Inflatable Marine Air Bag


    Diameter

    Working

    Pressure

    Working

    Height

    Bearing Capacity
    KN/mTon/m
    D=1.0m0.14Mpa0.6m87.968.98
    0.5m109.9611.22
    0.4m131.9513.46
    D=1.2m0.12Mpa0.7m94.259.62
    0.6m113.1011.54
    0.5m131.9513.46
    0.4m150.8015.39
    D=1.5m0.10Mpa0.9m94.259.62
    0.8m109.9611.22
    0.7m125.6612.82
    0.6m141.3714.43
    0.5m157.0816.03
    D=1.8m0.09Mpa1.1m98.9610.10
    1.0m113.1011.54
    0.9m127.3312.98
    0.8m141.3714.43
    0.7m155.5115.87
    0.6m169.6517.31
    D=2.0m0.08Mpa1.2m100.5310.26
    1.1m113.1011.54
    1.0m125.6612.82
    0.9m138.2314.11
    0.8m150.8015.39
    0.7m163.3616.67
    0.6m175.9317.95
    * Other size can be produced follow client's requirements.

    Features


    High-Quality Synthetic Rubber
    Our ship launching airbags are made of top-grade synthetic rubber material, ensuring excellent wear resistance and load-bearing capacity. This makes them highly reliable and durable for all your ship launching needs.


    Even Load Distribution
    The airbags are designed to distribute the load evenly during the ship launching process. This cushioning effect minimizes the impact on the vessel, ensuring a safe and smooth launch or dry-docking operation.


    Flexibility and Adaptability
    Our airbags are adaptable to different ship sizes and shapes. They can easily conform to the vessel's contours, providing a secure and snug fit. This versatility makes our airbags suitable for a wide range of ship launching and upgrading projects.


    Easy Installation and Remova
    Installing and removing our ship launching airbags requires minimal manpower and equipment. They can be quickly inflated and deflated, saving time and resources during the ship launching process. This user-friendly feature enhances the efficiency and convenience of using our airbags.


    Applications


    ● Shipbuilding
    ● Ship repair and maintenance
    ● Salvage operations
    ● Offshore installation
    ● Submarine launching
    ● Bridge construction
    ● Culvert installation
    ● Dock and wharf construction


    Advantages


    Rich Manufacturing Experience
    Our factory has been specializing in producing ship launching airbags for many years and has accumulated abundant experience in manufacturing, designing, and servicing. With our expertise, we can produce airbags with high-quality and precise specifications that meet the needs of our customers.


    High-quality Materials Selection
    We only use top-grade materials in producing our airbags to ensure their high-performance and durability. Our materials undergo stringent quality checks to ensure that they can withstand the pressure and stress that ship launching and other marine applications require.


    Advanced Production Technology
    Our factory uses the latest technology and equipment in producing our airbags. We have machines that can produce airbags of varying lengths and diameters, ensuring that we can meet the requirements of all types of boats and ships.


    Customized Solutions and Flexible Production Capabilities
    We understand that every customer's requirement is unique, and we offer customized solutions to meet their different needs. Our production processes are also flexible, allowing us to produce airbags in small or large quantities, depending on the customer's needs. With our custom solutions and flexibility, we can provide quick turnaround times for customers with urgent orders.
